| Place of Origin: | Hefei, China |
|---|---|
| Brand Name: | FUYUN |
| Certification: | ISO, ASTM, SASO, GB, SONCAP, BV |
| Model Number: | 0.5MM |
| Minimum Order Quantity: | 1550 square meters |
| Price: | USD 0.35-1.65 square meters |
| Packaging Details: | packed in roll with pipe core, woven bags, and belts |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, L/C, D/A, D/P, Western Union, MoneyGram, Paypal |
| Supply Ability: | 25 Tons per Day |
| Application: | Animal Waste Containment, Concrete Tank Liners, Mining Sites, Washing Pool, Coal Mining,Heap Leach Pads Landfills. Solid Waste Landfill Capping Vertical Cutoff Walls Irrigation Ponds. Farm Ponds. Agricultural Ponds Water Conveyance, Canals Aquaculture Hydr | Material: | HDPE, PVC, LDPE, Polyethylene, LLDPE, EVA |
|---|---|---|---|
| Function: | Antiseepage, Isolate, Protect, Cover | Product Name: | HDPE LDPE Animal Waste Containment Isolation Black Geomembrane Fabric Liners Anti Seepage Cover |
| Thickness: | 0.5mm | Certificate: | ASTM, EN, ISO, GB, GM13 |
| Origin: | Made In China | Color: | Black |
| High Light: | Oxygen Containment Geomembrane Fabric,0.5mm Thickness Geomembrane Fabric,Isolate Geomembrane Fabric |
||
Oxygen Containment HDPE LDPE Geomembrane Fabric Black Anti Seepage Cover 0.5mm Thickness
Quick Detail:
Production Description:
Anti-seepage HDPE geomembrane is a geomembrane manufactured from verified top-quality high-density polyethylene (HDPE) resins to meet the most stringent usage requirements. Durability and resistance in the waterproofing of all types of storage or encapsulation of liquids or residues.
It contains approximately 97.5% polymer and 2.5% carbon black, antioxidants and thermal stabilisers. It does not contain additives that can migrate or cause fragility over time. It geomembranes are manufactured under strict quality control.
It has excellent temperature adaptability, weldability, tolerance and aging resistance, chemical corrosion resistance, environmental stress cracking resistance and anti pierce performance. Therefore, it is especially suitable for underground engineering, mining engineering, sewage and waste residue treatment plant as impermeable materials.
Specification:
| Item | Properties | Unit | Thickness | |||||
| 1.0 | 1.25 | 1.5 | 2.0 | 2.5 | 3.0 | |||
| 1 | Roughness Height | mm | 0.25 | |||||
| 2 | Minimum Density | g/cm3 | 0.939 | |||||
| 3 | Breaking Strength | N/mm | 10 | 13 | 16 | 21 | 26 | 32 |
| 4 | Elongation at Break | % | 100 | |||||
| 5 | Right Angle Tear Strength | N | 125 | 156 | 187 | 249 | 311 | 374 |
| 6 | Puncture Strength | N | 267 | 333 | 400 | 534 | 667 | 800 |
| 7 | Stress Crack Resistance | Hrs | 300 | |||||
| 8 | Carbon Black Content (range) | % | 2.0-3.0 | |||||
| 9 | Low Temperature Impact Embrittlement at -70℃ | / | ok | |||||
| 10 | Water Vapor Permeability Coefficient(gNaN/cm2.s.p.a) | / | ≤1.0*10-13 | |||||
| 11 | Dimensional Stability | % | ±2 | |||||
Applications:
Solid Waste Landfills, Hazardous Waste Landfills and C & D Landfills
Animal Waste Containment
Power Plants
Aquaculture
Concrete Tank Liners
Advantage:
● Reduces Disease Risk
- Reduces suitability of the environment for bacteria growth in the pond
- Minimize spreading of disease from pond to pond
- Reduces need for medication thus resulting in economical and quality drug-free produce
● Water Conservation and Quality
- Prevents water loss
- Reduces pumping costs
- Easy to control water salinity and pH
● Oxygen Containment
- Prevent oxygen from dissipating into soil
- Lower electricity demand due to lesser oxygen production devices
● Efficient Harvesting
- Efficient harvesting with both net method or pond draining method
- Harvest duration is reduced and shrimp freshness is enhanced
● Efficient Waste Removal
- Rapid removal of sediments at pond base
- Pond cleaning drain system is easily integrated with HDPE liner
Package:
all products will be packed in woven bags with belt, and we gurantee the product good when customer receive it.
Packaging Details:
Neutral package of Pond Liner Material
Roll Size: 4m-7.0m
Or packed according to customers' requirements such as mark the company Logo
As example:
Specification 20ft container 40ft container
0.5mm 5.8/7*420m/roll 16rolls/38976m2 19rolls/55860m2
0.75mm 5.8/7*280m/roll 16rolls/25984m2 19rolls/37240m2
1mm 5.8/7*210m/roll 16rolls/19488m2 19rolls/27930m2
1.5mm 5.8/7*140m/roll 16rolls/12992m2 19rolls/18620m2
2.0mm 5.8/7*105m/roll 16rolls/9744m2 19rolls/13965m2
weight: 129g-188g/m2
