Home ProductsGeotech Fabric

Sewage Treatment Plant Geomembrane Lining Seepage Control

Sewage Treatment Plant Geomembrane Lining Seepage Control

Sewage Treatment Plant Geomembrane Lining Seepage Control
video
Sewage Treatment Plant Geomembrane Lining Seepage Control
Product Details:
Place of Origin: Hefei, China
Brand Name: FUYUN
Certification: SASO, BV, ISO, GB, SONCAP
Model Number: 0.5MM
Payment & Shipping Terms:
Minimum Order Quantity: 2000 square meters
Price: USD 0.75-1.65 square meters
Packaging Details: packed in roll with woven bags, pipe core and belts
Delivery Time: 7 Days
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram, Paypal
Supply Ability: 25 Tons per Day
Contact Now
Detailed Product Description
Application: Sewage Plant, Water Conveyance (Canal Liners), Sea Cucumber, Fishpond, Aquaculture, Shrimp Pond Material: LLDPE, HDPE, LDPE, EVA, PVC, Polyethylene
Function: Anti Erosion, Seepage Control, Impermeable, Protect Product Name: Sewage Treatment Plant Geomembrane Lining Seepage Control High Bearing Capacity
Thickness: 0.5mm Length: 50m, Customize
Colour: Black Origin: Made In China
High Light:

Sewage Treatment Plant Geomembrane Fabric

,

Anti Erosion Geomembrane Lining

,

Geomembrane Fabric Seepage Control

Sewage Treatment Plant Geomembrane Lining Seepage Control High Bearing Capacity



Quick Detail:

  • material: LLDPE, HDPE, EVA, PVC, polyethylene
  • length: 50m
  • width: 8m
  • thickness:  0.5mm
  • function: seepage control, impermeable, protect
  • application: Water Conveyance (Canal Liners), sea cucumber, fishpond, shrimp pond, aquaculture, sewage plant

Production Description:



HDPE geomembrane’s full name “High-Density Polyethylene Geomembrane”, have good environmental stress cracking resistance, low-temperature resistance,anti-aging, corrosion resistance, and the use of temperature range (-60℃ + 60℃) and a life of 60 years, widely used in waste landfill, sewage treatment plant, tailings disposal such as seepage control projects.



How to install in ponds lining and how to use in Biofloc system ?

Ponds:
Pond liners used for lining need to be protected from sharp objects (for example, stones) below the liner and from being punctured by any objects in the water body. Protection can be provided with layers of sand, geotextiles (particularly needle-punched nonwovens) and other materials. Pond liners are manufactured in rolls or accordion-folded on pallets. When deployed in the field their edges and ends are overlapped and seamed together. Sealing is done through thermal fusion, solvents and adhesives.

The edge of the pond liner is generally rolled over the top of the soil slope and secured in an anchor trench or it can be fixed to a vertical wall made of wood or concrete.





Specification:



general parameter:

Thickness 0.15-3.0mm & customer ' s requirement
Width 1-8m & customer ' s requirement
Length 50-200m & customer ' s requirement
Material HDPE
Color Black,White,Green,Blue & customer ' s requirement
Surface Smooth
Package Double layers woven bag, and add two strap & customer ' s requirement
Shipping Marks support
Production Standard GRI,ASTM,GB or other standard



specific parameter:

Item Properties Unit Thickness
1 Thickness mm 0.25 0.35 0.5 0.75 1 1.25 1.5 2
2 Density g/m3 0.94
3 Stretch Yield Strength (horiz & vet) N/mm 3.75 5 7.5 11 15 18 22 29
4 Stretch Break Strength (horiz & vet) N/mm 6.75 13.5 19 20 27 33 40 53
5 Yield Elongation (horiz & vet) % 12
6 Break elongation (horiz & vet) % 700
7 Angle Tear Strength (horiz & vet) N 31.25 45 62.5 93 125 156 187 249
8 Puncture Strength N 80 150 160 240 320 400 480 640
9 Stress Crack Resistance Hrs 300
10 Carbon Black Content (range) % 2.0-3.0
11 Carbon Black Dispersion / not more than 1 case grade 3 in 10 samples, grade 4 & 5 is not allowed
12 Oxidation Induction Time(OIT) Standard OIT 100 min
High Pressure OIT 400 min
13 Thermal Aging at 85 Standard OIT(min.ave.) retained after 90 days 55%
High Pressure OIT(min.ave.) retained after 90 days 80%
14 UV Resistance Standard OIT (min.ave.) 50%
High Pressure OIT (min.ave.) retained after 1600 hrs 50%






Application:

  • Mining. An HDPE geomembrane can prevent contamination of water and soil by providing a highly resistant barrier to chemicals produced during the extraction of precious metals.
  • Landfills. Highly resistant to hazardous chemicals HDPE has long been the lining of choice for this application. Used as either primary or secondary containment/ caps with or without GCL.
  • Irrigation Canals. To prevent water loss from seepage of water for man-made canals.
  • Tank Liners. Steel and concrete tanks are easily lined to prevent seepage loss. Also used as secondary lining under tanks in the petrochemical industries.



Sewage Treatment Plant Geomembrane Lining Seepage Control 0

Sewage Treatment Plant Geomembrane Lining Seepage Control 1



Advantage:



1. Good flexibility

2. For service temperature range:-70°C~110°C

3. Corrosion resistance, aging resistance

4. Excellent environmental stress cracking resistance property

5. High tensile strength and elongation

6. Lightweight, Economical & Flexibl
7. Tear & puncture resistant, Rugged strength
8. High hydrostatic resistance UV resistant
9. Minimal thermal expansion & contraction



Package:



Rolling with pipe in core, double layer woven bags with strengthened belt for unloading convenience and protecting.

Packaging Details:

Neutral package of Pond Liner Material

Roll Size: 4m-7.0m

Or packed according to customers' requirements such as mark the company Logo

As example:

Specification 20ft container 40ft container

0.5mm 5.8/7*420m/roll 16rolls/38976m2 19rolls/55860m2

0.75mm 5.8/7*280m/roll 16rolls/25984m2 19rolls/37240m2

1mm 5.8/7*210m/roll 16rolls/19488m2 19rolls/27930m2

1.5mm 5.8/7*140m/roll 16rolls/12992m2 19rolls/18620m2

2.0mm 5.8/7*105m/roll 16rolls/9744m2 19rolls/13965m2


weight: 129g-188g/m2

Sewage Treatment Plant Geomembrane Lining Seepage Control 2





Factory Show:



Sewage Treatment Plant Geomembrane Lining Seepage Control 3



Sewage Treatment Plant Geomembrane Lining Seepage Control 4

Why Choose us?



Sewage Treatment Plant Geomembrane Lining Seepage Control 5



FAQ:



Sewage Treatment Plant Geomembrane Lining Seepage Control 6
