3.0mm Column Points Geomembrane Liner Heavy Duty 50m/Roll

Basic Information
Place of Origin: Hefei, China
Brand Name: FUYUN
Certification: ISO, GB, BV, SASO, SONCAP
Model Number: 3.0MM
Minimum Order Quantity: 1000 square meters
Price: USD 1.5-8.5 square meters
Packaging Details: packed in roll with woven bags
Delivery Time: 5 Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal
Supply Ability: 3000 square meters per Day
Detail Information
Thickness: 3.0mm Width: 6m
Length: 50m/roll Application: Landfill, Steep Slope, Chemical Industry, Oil Rig Platform
Material: HDPE,EVA,PVC,polyethylene, LLDPE Function: Drainage, Ventilation, Antiseepage
Weight: 150gsm Product Name: 3.0mm Column Pionts Heavy Duty Non Skid Oil Rig Platform Floor Under Mug Tanks Geomembrane Liner3.0mm Column Pionts Heavy Duty Non Skid Petroleum Tanks Geomembrane Liner
High Light:

3.0mm HDPE Geomembrane Liner

,

Column Points Geomembrane Liner

,

50m/roll HDPE Geomembrane Liner


Product Description

3.0mm Column Pionts Heavy Duty Non Skid Petroleum Tanks Geomembrane Liner

Quick Detail:

  • material: HDPE geomembrane
  • length: 50m
  • width: 7.0m
  • thickness: 3.0mm
  • production standard: GRI,ASTM,GB, ISO
  • application: landfill,steep slope, chemical industry


Production Description:

HDPE column point rough surface geomembrane is divided into single column point geomembrane and double column point geomembrane; the products produced by this production process have excellent mechanical properties, good elongation, and stable chemical properties while retaining the original resin itself. Above, by adding a certain proportion of functional additives through melting, extrusion, rolling, drawing and other processes, the product’s tensile, abrasion, and puncture resistance properties are enhanced. The mechanical properties of the product are better than those of the rough surface produced by similar common processes. The anti-slip geomembrane is increased by nearly 3 times. The pillar points on the membrane surface are rolled and rolled by a special model. The pillar points are evenly distributed, beautiful, and the friction coefficient is improved. The front and back sides of the membrane can be thermally fused with different materials and colors. In engineering applications, the front and back of the product can be set according to geological conditions and engineering requirements.



Column point geomembrane can increase the coefficient of friction with the contact surface, enhance the anti-skid function of the geomembrane, especially suitable for slopes, steep slopes and heavy straight anti-seepage, improve engineering stability. Effectively prevent the geomembrane from sliding down and reduce the weld seam and the membrane itself Stress.


Column Pionts anti skid geomembrane is produced by processing of hot-welt, extrude, press pre-long. extension in reasonable controlling, which increase products' tensile strength puncture strength, abrasion resistance.

The Points evenly distributed with increased friction, and the appearance is very beautiful. The two sides of geomembrane can be of melted together by different colour and materials. We can produce right side or reverse of products according to geological conditions and project requirements.

It retains suprior mechanical property and excellent elongation and stable chemical property of raw materials. And through adding functional auxiliaries agents in fixed proportion, which improved product's function of anti-acid&alkali and anti-corrosion. It's tensile strength 3 times higher than normal 1 textured geomembrane.


Specification:

Item Properties Index
1 Substrate Thickness (mm) 0.5-2.5
2 Height of Supporting Point (mm) 0.6-0.75
3 Tensile Strength (horiz & vet)Mpa 25
4 Elongation at Break (horiz & vet) % 550
5 Angle Tear Strength (horiz & vet) N/mm 110
6 Resistance to Environmental Stress Cracking F20*h 1500
7 Carbon Black Content (range) % 2-3
8 Impact Embrittlement at -70 yes
9 Oxidation Induction Time at 200 20min



Application:


1. River Embankment, lake dam,tailing,sawage, reservior, cana,storage ect.
2. Antiseepage of undergroup, basement, tunnel.
3. Antiseepage of subgrade and graund work in salty soil.
4. The antiseepage in plane direction of embankment and dam, the antlseepage intranverse direction of groudwork. canstruction cofferdam, scrap yard.
5. Breeding farm of fresh water and sea water
6. Embankment of road, highway and railway,water proof layer of swelling clay and collapsed loess
7. Water proof of roof top.



3.0mm Column Points Geomembrane Liner Heavy Duty 50m/Roll 0


Advantage:

  • Effective isolation of liquids and gases
  • The flexibility of the material is suitable for landfill closure
  • Anti leakage
  • Moisture-proof
  • Isolation
  • Root resistance
  • Anti puncture
  • Resistance to environmental stress cracking



Package:

Rolling with pipe in core, double layer woven bags with strengthened belt for unloading convenience and protecting.

3.0mm Column Points Geomembrane Liner Heavy Duty 50m/Roll 1


Factory Show:

3.0mm Column Points Geomembrane Liner Heavy Duty 50m/Roll 2


Why Choose us?

3.0mm Column Points Geomembrane Liner Heavy Duty 50m/Roll 3

FAQ:

3.0mm Column Points Geomembrane Liner Heavy Duty 50m/Roll 4
