| Place of Origin: | Hefei,China |
|---|---|
| Brand Name: | FUYUN |
| Certification: | ISO, GB, BV, SASO, SONCAP |
| Model Number: | 150/0.25 |
| Minimum Order Quantity: | 2000 Square Meters |
| Price: | USD 0.15-5.5 Square Meter |
| Packaging Details: | Rolling in Woven Bag, Width 2-6m, Length 50-100m |
| Delivery Time: | 7 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal |
| Supply Ability: | 25 Tons per Day |
| Color: | White | Material: | High-density Polye,Polypropylene,PP HDPE PET,Polyester |
|---|---|---|---|
| Length: | 50-100m,or Customerized | Width: | 2m-6m Or As Required |
| Product Name: | Anti-seepage Filtering Reinforce 150/0.25 Composite Compound Black Geomembrane Made In China | Usage: | Underground Drainage System,reinforeced And Drainage |
| Function: | Protection,Waterproofing,anti-seepage,isolation | Roll Length: | 50m Or At Your Request |
| Package: | Woven Bags,in Roll | Weight: | 400-1000g/m2 |
| High Light: | 400g/M2 HDPE Lining For Water Tank,400g/M2 Waterproof Geomembrane,PET Waterproof Geomembrane |
||
Anti-seepage Filtering Reinforce 150/0.25 Composite Compound Black Geomembrane Made In China
Quick Detail:
weight: 400-1000g/㎡
thickness: 0.2-0.8mm
function: Isolation, Drainage, Anti-seepage, Guard, Reinforce, filtering
color: black
Product Description:
Composite geomembrane is a kind of composite product, which is generally divided into 2-cloth-1-film and 1-cloth-1-film. 2-cloth-1-film refers to that the upper and lower sides of geomembrane are composite with geotextile, and 1-cloth-1-film refers to that one side (upper or lower side) of geomembrane is composite with geotextile. Because the middle waterproof layer (geomembrane) of composite geomembrane is protected by geotextile, it can be used in field anti-seepage engineering with complex construction environment.
Composite geomembrane can be used for seepage control of various water conservancy projects, such as river seepage prevention project, river treatment project, artificial lake seepage control project, landscape lake seepage prevention project, dike seepage prevention project, canal seepage prevention project etc.
Product Specification:
Technical Parameter:
| Weight(g/㎡) | 400 | 500 | 600 | 700 | 800 | 900 | 1000 | |
| PE CG Thickness(mm) | 0.20-0.35 | 0.30-0.60 | ||||||
| Common Specs | 1-cloth-1-film(g/㎡) | 150/0.25 | 200/0.3 | 300/0.3 | 300/0.4 | 300/0.5 | 400/0.5 | 400/0.6 |
| 2-cloth-1-film(g/㎡) | 100/0.2/100 | 100/0.3/100 | 50/0.3/150 | 200/0.3/200 | 200/0.4/200 | 200/0.5/200 | 50/0.5/250 | |
| Quality Deviation per Unit Area(%)≤ | -10 | |||||||
| Fracture Strength(KN/m) ≧ | 5 | 7.5 | 10 | 12 | 14 | 16 | 18 | |
| Break Elongation(%) | 30-100 | |||||||
| Tear Strength(KN) ≧ | 0.15 | 0.25 | 0.32 | 0.4 | 0.48 | 0.56 | 0.62 | |
| CBR Breakout Force(KN) ≧ | 1.1 | 1.5 | 1.9 | 2.2 | 2.5 | 2.8 | 3 | |
| Vertical Permeability Coefficient(cm/s) ≤ | 10-12 | |||||||
| Hydrostatic Pressure Resistance (Mpa)≧ | 0.4-0.6 | 0.6-1.2 | ||||||
| 1. PE CG Thickness(mm) 0.2-0.8mm | ||||||||
| 2.According to the technical requirements of the demander, the welding edge of composite geomembrane can be reserved or not | ||||||||
Advantage:
Application:
Package:
Rolling with pipe in core, Double layer woven Bags with strengthened belt for unloading convenience and protecting.
Delivery:
Delivery product will be loaded carefully to make sure it can be well received. 20GP Container can load around 19 tons, 40HQ 25 tons
Supply Ability:
25 Tons Per Day
Factory Show:
FAQ:
