PET Woven Geotextile High Strength Low Deformation 300/50 KN/m Earthwork Construction

Basic Information
Place of Origin: Hefei, China
Brand Name: FUYUN
Certification: CE, ISO, SGS, BV, GB, ASTM
Model Number: 300/50 kn/m
Minimum Order Quantity: 30000 Square Meters
Price: USD 0.35-5.05 Square Meter
Packaging Details: packed as roll in woven bag, width: from 1m to 5m, length: from 55m to 260m
Delivery Time: 7 Days
Payment Terms: T/T, D/A, Western Union, D/P, MoneyGram, L/C, Paypal
Supply Ability: 28.5 Tons per Day
Detail Information
Product Name: PET Woven Geotextile High Strength Low Deformation 300/50 KN/m Earthwork Construction Weight: 300/50 Kn/m
Material: Pet, Pp Rolling Size: Width: From 1m To 6m, Length: From 60m To 260m
Function: Protect Water, Isolate, Reinforce, Drainage, Separate Soil Application: Road, Subsoil Drain, Gabion Walls, Water Source Project, Coastal, Flood Dam
Origin: Made In China

Product Description

PET Woven Geotextile High Strength Low Deformation 300/50 KN/m Earthwork Construction




Quick Detail:
material: polyester, polypropylene(PET, PP)
function: protect, isolate, reinforce, drainage, enhance, separate soil
weight: 760g
application: road, tidal reclamation project, coastal, flood dam, subsoil, coastal beach


Product Description:


Hefei Xuqiu Environmental Protection Co., Ltd offers a range of woven geotextiles from lightweight fabrics used for basic separation of incompatible soils to medium and high strength materials for ground reinforcement solutions. Our woven geotextiles are manufactured from inert polypropylene and polyester and therefore not only safe for use but also resistant to attack from microbial attack and most chemicals that naturally occur in soil.



PET woven geotextile has the features of high tensile strength, excellent CBR value, good resistance to mineral acids and weak alkalis, disintegrates to strong alkalis and high temperatures, etc. The ultimate tensile strength of PET woven geotextile can reach up to 1200kN/m in uniaxial directions, so PET geotextile is the cost-effective geotextile fabric for reinforcement and stabilization applications, especially for construction projects demanding both high-strength reinforcement and separation functions.


Technical Parameters:





Item Specification
Material Polyester
Breaking Strength in MD(KN/m) 35 50 65 80 100 120 140 160 180 200 250
Breaking Strength in CD(KN/m) 35 50 65 80 100 120 140 160 180 200 250
Elongation at Break(%) MD=35; CD=30
Width Variation, % ±0.1
CBR Mullen Burst Strength, KN 2.0 4.0 6.0 8.0 10.5 13.0 15.5 18.0 20.5 23.0 28.0
Seive Size O90(O95) mm 0.07-0.50
Tearing Strength, KN 0.5 0.8 1.1 1.3 1.5 1.7 1.9 2.1 2.3 2.5 3
Weigth, g/m2 140 220 260 320 390 450 530 600 680 760 950

















































Application:



Due to the high tensile strength, good tear strength and excellent CBR value features, pet woven geotextile is ideal and cost effective geosynthetic material for stabilization and reinforcemement applications. Followed are some of them.

Earthwork Construction
Base reinforcement
Steep side slope reinforcement
Embankment stablization and reonforcement
Bridging over sinkholes
Roadway and Railway Construction
Base Reinforcement

PET Woven Geotextile High Strength Low Deformation 300/50 KN/m Earthwork Construction 0


PET Woven Geotextile High Strength Low Deformation 300/50 KN/m Earthwork Construction 1



Advantage:



1. High strength, low deformation
2. Durability: steady property, not easy to resolved, air slaked and can keep the original property long term
3. Anti-erosion: anti-acid, anti-alkali, resists insects and mould
4. Permeavility: could control the sieve size to retain certain permeability


​​​Package:

all products will be packed well with woven bags and tight belts, or packed according to customer's requirement,
3Tons per 20ft container;
5Tons per 40ft container;
8Tons per 40HQ container.

 PET Woven Geotextile High Strength Low Deformation 300/50 KN/m Earthwork Construction 2


Delivery:

all products will be delivered in time according to the requirement,


Factory Show:

PET Woven Geotextile High Strength Low Deformation 300/50 KN/m Earthwork Construction 3

PET Woven Geotextile High Strength Low Deformation 300/50 KN/m Earthwork Construction 4


Why Choose US:

PET Woven Geotextile High Strength Low Deformation 300/50 KN/m Earthwork Construction 5

FAQ:

PET Woven Geotextile High Strength Low Deformation 300/50 KN/m Earthwork Construction 6
