1.25mm Anti Seepage HDPE Geomembrane Lining For Mining Tailing Pond

Basic Information
Place of Origin: Hefei, China
Brand Name: FUYUN
Certification: ISO, GB, BV, SONCAP, ASTM
Model Number: 1.25MM
Minimum Order Quantity: 2000 square meters
Price: USD 0.55-2.05 square meters
Packaging Details: Woven Bags, 20GP loads 19 tons, 40HQ loads 25 tons
Delivery Time: 10Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal
Supply Ability: 25 Tons per Day
Detail Information
Length: 50m/roll Application: Mining Tailing Pond, Lobster Tank, Fish Pond, Shrimp Pond
Material: LLDPE, HDPE, LDPE, Polyethylene, EVA, PVC Function: Anti Seepage, Temperature Control, Oxygenation, High Bearing Capacity
Density: 0.90~ 0.96 G/cm Product Name: Mining Tailing Pond Geomembrane Lining Antiseepage HDPE 1.25mm Thickness
Certificate: ASTM, ISO, GM13 Origin: Made In China
High Light:

Anti Seepage HDPE Geomembrane Lining

,

Geomembrane Lining 1.25mm Thickness

,

50m/roll HDPE Geomembrane Lining


Product Description

Mining Tailing Leachate Pond Geomembrane Lining Antiseepage HDPE 1.25mm Thickness



Quick Detail:

  • material: HDPE, LDPE
  • length: 50m
  • width: 6m
  • thickness:  1.25mm
  • function: anti seepage, oxygenation, temperature control
  • application: fish pond, fish tank, shrimp tank, lobster tank

Production Description:



Geomembrane is basically used in many civil projects as it works as a flat sheet designed for controlling migration of fluids and soils. Keeping in mind the set international quality standards, our Geomembrane sheets are manufactured using premium quality High Density Polypropylene material. The offered HDPE Geomembrane is made available for clients in various sizes, finishes and thicknesses as per customer’s requirement and are cost effective. We also manufacture AMS HD Sheet which is a high mass polyethylene Geomembrane manmade by Blow Film process. Made by means of resins shaped under the greatest rigorous quality panels.



Sanitary Landfill, Mining and Leachate Ponds :

Geomembrane liners are extensively used in sanitary landfills, mining operations, canals, power plants, dams, heap leach pads and leachate collection ponds. For a complete containment protection, sanitary landfills are lined, capped or covered with Geopoly HDPE geomembrane lining systems of both smooth and textured surfaces and also LLDPE geomembrane liners. Hazardous leachate from landfill cells are channeled into lined leachate collection ponds for further treatment.



Table1(a) – High Density Polyethylene (HDPE) Geomembrane -Smooth





  Properties Test       Test Value       Testing Frequency
    Method 30 mils 40 mils 50 mils   60 mils 80 mils 100 mils 120 mils (minimum)
Thickness (min. ave.) D5199 nom. Nom. Nom.   Nom. Nom. Nom. Nom. Per roll
· lowest individual of 10 values   -10% -10% -10%   -10% -10% -10% -10%
Density mg/l (min.) D 1505/D 792 0.940 g/cc 0.940 g/cc 0.940 g/cc   0.940 g/cc 0.940 g/cc 0.940 g/cc 0.940 g/cc 200,000 lb
Tensile Properties (1) (min. ave.) D 6693                 20,000 lb
· yield strength Type IV 63 lb/in. 84 lb/in. 105 lb/in.   126 lb/in. 168 lb/in. 210 lb/in. 252 lb/in.
· break strength   114 lb/in. 152 lb/in. 190 lb/in.   228 lb/in. 304 lb/in. 380 lb/in. 456 lb/in.
· yield elongation   12% 12% 12%   12% 12% 12% 12%
· break elongation   700% 700% 700%   700% 700% 700% 700%
Tear Resistance (min. ave.) D 1004 21 lb 28 lb 35 lb   42 lb 56 lb 70 lb 84 lb 45,000 lb
Puncture Resistance (min. ave.) D 4833 54 lb 72 lb 90 lb   108 lb 144 lb 180 lb 216 lb 45,000 lb
Stress Crack Resistance (2) D5397 300 hr. 300 hr. 300 hr.   300 hr. 300 hr. 300 hr. 300 hr. per GRI-GM10
    (App.)
Carbon Black Content (range) D 4218 (3) 2.0-3.0% 2.0-3.0% 2.0-3.0%   2.0-3.0% 2.0-3.0% 2.0-3.0% 2.0-3.0% 20,000 lb
Carbon Black Dispersion D 5596 note (4) note (4) note (4)   note (4) note (4) note (4) note (4) 45,000 lb
Oxidative Induction Time (OIT) (min. ave.) (5)                   200,000 lb
(a) Standard OIT D 3895 100 min. 100 min. 100 min.   100 min. 100 min. 100 min. 100 min.
  — or —
(b) High Pressure OIT D 5885 400 min. 400 min. 400 min.   400 min. 400 min. 400 min. 400 min.
Oven Aging at 85°C (5), (6) D 5721
(a) Standard OIT (min. ave.) - % retained after 90 days D 3895 55% 55% 55%   55% 55% 55% 55% per each
  — or —                   formulation
(b) High Pressure OIT (min. ave.) - % retained after 90 days D 5885 80% 80% 80%   80% 80% 80% 80%
UV Resistance (7) D 7238
(a) Standard OIT (min. ave.) D 3895 N.R. (8) N.R. (8) N.R. (8)   N.R. (8) N.R. (8) N.R. (8) N.R. (8) per each
  — or —                   formulation
(b) High Pressure OIT (min. ave.) - % retained after 1600 hrs (9) D 5885 50% 50% 50%   50% 50% 50% 50%



Specification:



general parameter:

Thickness 0.15-3.0mm & customer ' s requirement
Width 1-8m & customer ' s requirement
Length 50-200m & customer ' s requirement
Material HDPE
Color Black,White,Green,Blue & customer ' s requirement
Surface Smooth
Package Double layers woven bag, and add two strap & customer ' s requirement
Shipping Marks support
Production Standard GRI,ASTM,GB or other standard



specific parameter:

Item Properties Unit Thickness
1 Thickness mm 0.25 0.35 0.5 0.75 1 1.25 1.5 2
2 Density g/m3 0.94
3 Stretch Yield Strength (horiz & vet) N/mm 3.75 5 7.5 11 15 18 22 29
4 Stretch Break Strength (horiz & vet) N/mm 6.75 13.5 19 20 27 33 40 53
5 Yield Elongation (horiz & vet) % 12
6 Break elongation (horiz & vet) % 700
7 Angle Tear Strength (horiz & vet) N 31.25 45 62.5 93 125 156 187 249
8 Puncture Strength N 80 150 160 240 320 400 480 640
9 Stress Crack Resistance Hrs 300
10 Carbon Black Content (range) % 2.0-3.0
11 Carbon Black Dispersion / not more than 1 case grade 3 in 10 samples, grade 4 & 5 is not allowed
12 Oxidation Induction Time(OIT) Standard OIT 100 min
High Pressure OIT 400 min
13 Thermal Aging at 85 Standard OIT(min.ave.) retained after 90 days 55%
High Pressure OIT(min.ave.) retained after 90 days 80%
14 UV Resistance Standard OIT (min.ave.) 50%
High Pressure OIT (min.ave.) retained after 1600 hrs 50%






Application:



1, Sanitary Landfill, Mining and Leachate Ponds;

2.Concrete, Pressed Steel Tanks and Secondary Containment;

3.Aquaculture Pond Liners;

4.Floating Covers, Covered Lagoons and CDM Biogas Digesters



1.25mm Anti Seepage HDPE Geomembrane Lining For Mining Tailing Pond 0

1.25mm Anti Seepage HDPE Geomembrane Lining For Mining Tailing Pond 1

1.25mm Anti Seepage HDPE Geomembrane Lining For Mining Tailing Pond 2

1.25mm Anti Seepage HDPE Geomembrane Lining For Mining Tailing Pond 3



Advantage:

  • High anti-seepage ratio
  • Chemical stability
  • Anti plant root system
  • Thermal aging resistance
  • High mechanic strength
  • Low cost
  • Environmental protection formulation
  • Rapid construction

Package:



Packaging Details:

Neutral package of Pond Liner Material

Roll Size: 4m-7.0m

Or packed according to customers' requirements such as mark the company Logo

As example:

Specification 20ft container 40ft container

0.5mm 5.8/7*420m/roll 16rolls/38976m2 19rolls/55860m2

0.75mm 5.8/7*280m/roll 16rolls/25984m2 19rolls/37240m2

1mm 5.8/7*210m/roll 16rolls/19488m2 19rolls/27930m2

1.5mm 5.8/7*140m/roll 16rolls/12992m2 19rolls/18620m2

2.0mm 5.8/7*105m/roll 16rolls/9744m2 19rolls/13965m2



1.25mm Anti Seepage HDPE Geomembrane Lining For Mining Tailing Pond 4
