| Place of Origin: | Hefei,China |
|---|---|
| Brand Name: | FUYUN |
| Certification: | ASTM, ISO, EN, GB, BV |
| Model Number: | TGSG20-20 |
| Minimum Order Quantity: | 2000 Square Meters |
| Price: | USD 0.55-2.30 Square Meter |
| Packaging Details: | Woven Bags, pallet, 50-100m/roll, Width 1-6m, Customized |
| Delivery Time: | 7 Days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal |
| Supply Ability: | 20000 Square Meters per Day |
| Application: | Retaining Wall, Copper Mining Coal Mining, Dam Slope Protection | Longitudinal Yield Elongation: | Less Than 16% |
|---|---|---|---|
| Temperature Resistance: | From -100 To 270 ℃ | Package: | Woven Bag, Customized |
| Tensile Strength: | 15-150KN/m | Feature: | Temperature Resistance, Anti-static, Light Weight, Long Life |
| Material: | High Molecular Polymer, Fiberglass | Product Name: | Retaining Walls Soil Reinforcement Stabilization Pp Biaxial Earthwork Fiberglass Geogrid Anti Static |
| High Light: | Pp Biaxial Fiberglass Geogrid,Antistatic Fiberglass Geogrid,Soil Reinforcement Fiberglass Geogrid |
||
Retaining Walls Soil Reinforcement Stabilization Pp Biaxial Earthwork Fiberglass Geogrid Anti Static
Quick Detail:
material: high molecular polymer
function: reinforce, strengthen road, prevent road cracks
advantage: high temperature resistance, low cold resistance, anti-aging and corrosion resistance
application: copper mining coal mining, dam slope protection
Product Description:
Depending on site conditions and wall height, retaining walls often require soil reinforcement. Geogrid is a geosynthetic material, made of polymers, that is used to reinforce soil behind retaining walls. Installed in horizontal layers between wall courses and extending into the soil behind a wall, geogrid stabilizes the soil and so increases a wall system's mass and stability.
Technical Parameter:
| item | TGSG15-15 | TGSG20-20 | TGSG30-30 | TGSG40-40 | TGSG45-45 | TGSG50-50 |
| Mass per unit area(g/m) | 300+/-30 | 330+/-30 | 400+/-40 | 500+/-50 | 550+/-50 | 550+/-50 |
| width(m) | 2.5 3.0 4.0 5.0 6.0 | |||||
| Longitudinal tensile yield(KN/m≧) | 15 | 20 | 30 | 40 | 45 | 50 |
| Transverse tensile yield(KN/m≧) | 15 | 20 | 30 | 40 | 45 | 50 |
| Longitudinal yield elongation(%≦) | 16 | |||||
| Transverse yield elongation(%≦) | 13 | |||||
| Tensile rate at longitudinal elongation of 2%(KN/m≧) | 5 | 8 | 11 | 13 | 16 | 19 |
| Tensile rate at transverse elongation of 2%(KN/m≧) | 7 | 10 | 13 | 15 | 20 | 24 |
| Tensile rate at longitudinal elongation of 5%(KN/m≧) | 8 | 10 | 15 | 16 | 25 | 27 |
| Tensile rate at transverse elongation of 2%(KN/m≧) | 10 | 13 | 15 | 20 | 22 | 23 |
Application:
(1) Reinforcement of roads, railways and airport roads
(2) Maintenance, reconstruction and widening of old road surface (asphalt road or cement concrete road)
(3) Reduces construction cost, extends service life of roads and prevents deflection cracks.
(4)It is applied in old asphalt cement pavement to reinforce the asphalt surface, and prevent diseases
(5)It is applied in cement pavement to reconstruct composite road surface, and restrain plate shrink to cause reflection crack
(6)It is applied in reconstruction project of road to prevent cracks caused by connection of old and new roads and differential settlement
(7)It is applied in reinforcement of soft earth bed, which is benefit for soft earth to absorb water and fix, restrain settlement effectively, and reinforce the strength of roadbed
(8)The semi-rigid base of new-built road is easy to produce shrinkage crack, fiberglass geogrid can reinforce the crack of the road surface caused by crack reflection.
Advantage:
•High Tear Strength
•Flexible and durable
•Excellent Creep Resistance
•UV resistance
•Cost effective
•High chemical and biological resistance
•High Tensile Strength and Low Elgongation
•Optimun stability of the junction strength of the grid
•Increased pull-out resistance and compound strength
•High resistance to installation damage and ease of installation
Package:
Rolling with pipe in core, double layer woven bags with strengthened belt for unloading convenience and protecting. Geogrid roll is packaging with nude package or woven bags, or Customers' request. Standard roll size: Width 3.95m * Length 50m for loading container.
Delivery:
Product will be loaded carefully to make sure it can be well received. 20GP Container can load around 19 tons, 40HQ 25 tons. It can be shipped in 7 days in normal season.
Factory Show:
Supply Ability:
more than 25 tons per day
