BV Welded Fiberglass Geogrid For Strengthening Reinforcing Cement Pavement

Basic Information
Place of Origin: Hefei,China
Brand Name: FUYUN
Certification: ISO, GB, CE,BV, EN
Model Number: 30-150KN
Minimum Order Quantity: 1000 Square Meters
Price: USD 0.5-1.5 Square Meter
Packaging Details: Woven Bags, 50-100m/roll, Width 1-6m, Customized
Delivery Time: 7 Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal
Supply Ability: 10000 Square Meters per Day
Detail Information
Width: 1-6m, Customized Scalation Rate: Less Than 4%
Temperature Resistance: From -100 To 280 ℃ Application: Road Construction, Cement Pavement
Tensile Strength: 30-150KN/m Feature: Temperature Resistance, Anti-static, Light Weight, Long Life
Material: High Molecular Polymer Product Name: SWelded 120KN PET PP Geogrid In Road Construction For Strengthening Reinforcing Cement Pavement
High Light:

Welded Fiberglass Geogrid

,

Fiberglass Geogrid Reinforcing Cement Pavement

,

Welded geogrid driveway


Product Description

Welded 120KN PET PP Geogrid In Road Construction For Strengthening Reinforcing Cement Pavement



Quick Detail:



material: high molecular polymer

function: reinforce, strengthen road, prevent road cracks

advantage: high temperature resistance, low cold resistance, anti-aging and corrosion resistance



Product Description:



Steel-Plastic Weld Geogrid With high strength steel wire (or other fiber), through special processing, and polyethylene (PE) or polypropylene (PP), and adding other additives by extrusion become composite high strength tensile band, and surface roughness is embossed, high strength reinforced geotextile. Welded Geogrid are warp knitted PP PE materials welded geogrid, it use PP PE as raw materials,through extruding to be rib belt which with very high tensile strength,then the belts warp knitted and welded by Ultrasonic welding machine to make it have high tensile strength in both Longitudinal and Transverse direction. This products mainly used for Soil stabilization,road sub-base reinforcement,aggregates confinement and improving the performance of road anti-pressure ability.



The material has great tensile strength in both longitudinal and transverse directions. This kind of structure can also provide a more effective bearing and diffusion of force in the soil, which is suitable for the reinforcement of large area permanent bearing foundation.



It also has high tensile strength and low elongation on both sides of the warp and weft, and has excellent properties such as high temperature resistance, low cold resistance, anti-aging and corrosion resistance.It is widely used in the reinforcement of asphalt pavement, cement pavement and subgrade, railway subgrade, dam slope protection, airport runway, sand control and other projects.

BV Welded Fiberglass Geogrid For Strengthening Reinforcing Cement Pavement 0





Technical Parameter:



1 Type TGDG30-30 TGDG50-50 TGDG80-80 TGDG100-100 TGDG120-120
2 Biaxial Ultimate Tensile Strength (KN/m≥) 30 50 80 100 120
3 Biaxial Ultimate Elongation (%≤) 3 3 3 3 3
4 Tensile Strength of Elongation at 1% (KN/m≥) 23 36 48 63 81






Application:

  • Soil stabilization
  • Sub-base reinforcement
  • Foundation support
  • Heavy duty pavements
  • Railway ballast reinforcement over soft foundations
  • Access roads to oil platforms


BV Welded Fiberglass Geogrid For Strengthening Reinforcing Cement Pavement 1


Advantage:

  • Increase the bearing capacity of road (ground) foundation and extend its service life
  • The construction is convenient, time-saving and labor-saving, the construction period is shortened, and the sequence cost is reduced
  • Prevention of cracks in culverts
  • Strengthen soil slope and prevent soil erosion
  • Reduce the thickness of cushion and save the cost
  • Stability and greening environment of grass net mat supporting slope
  • The bidirectional geogrid can replace the metal mesh and be used in the underground frame top mesh of coal mine


Package:

Rolling with pipe in core, double layer woven bags with strengthened belt for unloading convenience and protecting.

BV Welded Fiberglass Geogrid For Strengthening Reinforcing Cement Pavement 2


Delivery:

Product will be loaded carefully to make sure it can be well received. 20GP Container can load around 19 tons, 40HQ 25 tons. It can be shipped in 7 days in normal season.

BV Welded Fiberglass Geogrid For Strengthening Reinforcing Cement Pavement 3


Factory Show:

BV Welded Fiberglass Geogrid For Strengthening Reinforcing Cement Pavement 4


Supply Ability:

more than 25 tons per day
